Sintered metal powder porous filter cartridge OD60*3*508
- Micron Rate:0.2um-100um
- Filtering precision:28%-50%
- SS Microporous filter
- COMPRESSIVE STRENGTH: 0.5-1.5MPa
- Product description: Stainless Steel Sintered Powder tubes,metal powder cartridges, porous stainless steel filters,Sintered Metal Powder Filter Element (porous metal filter),sintered titanium powder filters (tubes),sinter
Product introduction
Sintered metal powder filter element
Manfre High Purity Steam Filters incorporate sintered porous stainless steel filter
media that ensures the effective retention of particles. The 316L SS filter elements
provide excellent chemical resistance and mechanical stability due to their special
design. Using Manfre High Purity Steam Filterelement can considerably reduce the
post-filtration costs of your system
Features
Porous sintered stainless steel construction
High flow rate with low differential pressure
High mechanical stability
High temperature range
Available in media grades 10, 20, and 40 µm
Welded end caps either flat end or centering cone
226 with locking flanges or 222 adapters with double “O” ring
Specifications
Nominal Dimensions | 10 inch Cartridge | 20 inch Cartridge | 30 inch Cartridge | 40 inch Cartridge |
Overall Length 1 | 10.75 Inch/273 mm | 20.75 Inch/527 mm | 30.75 Inch/781 mm | 40.75 Inch/1035 mm |
Outside Diameter | 2.5 Inch/63.5 mm | 2.5 Inch/63.5 mm | 2.5 Inch/63.5 mm | 2.5 Inch/63.5 mm |
Filtration Area | 0.54 Ft2/0.05 m2 | 1.09 Ft2/0.10 m2 | 1.63 Ft2/0.15 m2 | 2.18 Ft2/0.20 m2 |
Filter Media | 316L SS | 316L SS | 316L SS | 316L SS |
End-caps, Adapter | 316L SS | 316L SS | 316L SS | 316L SS |
Maximum Forward Differential Pressure in Air, Oxygen or Nitrogen | 250 psid (17.23 Bar) | 250 psid (17.23 Bar) | 250 psid (17.23 Bar) | 250 psid (17.23 Bar) |
Maximum Reverse Differential Pressure in Air Oxygen or Nitrogen | 250 psid (17.23 Bar) | 250 psid (17.23 Bar) | 250 psid (17.23 Bar) | 250 psid (17.23 Bar) |
Maximum Operating Temperatures |
450°C (842°F) @ 125 PSIG |
450°C (842°F) @ 125 PSIG |
450°C (842°F) @ 125 PSIG |
450°C (842°F) @ 125 PSIG |
Cartridge Connections Double O-Ring |
226 with Locking Flange or 222 | 226 with Locking Flange or 222 | 226 with Locking Flange or 222 | 226 with Locking Flange or 222 |
End caps |
Flat end cap or centering cone end cap |
Flat end cap or centering cone end cap |
Flat end cap or centering cone end cap |
Flat end cap or centering cone end cap |
