stainless steel filter housing

Working principle:

Precision filter is used to shaping filter, under pressure, the liquid through the filter, the filter residue left in the pipe wall, the filtrate flow through the filter, so as to achieve the purpose of filtering.

Shaping filter: filter, filter, filter cloth, filter, sintered wound filter, meltblown filter etc.. Because of the different filter, filter pore size is not the same. Precision filter is interposed between the sand (coarse filter) and a filtration ultrafiltration, filtering aperture is in commonly 0.5 ~ 120 μ m range. The same form of filter, according to size can be divided into different specifications.

Wirewound filter (also known as the honeycomb filter) has two kinds: one kind is polypropylene fiber, polypropylene frame filter, the maximum temperature of 60°C ; another is the cotton fiber, stainless steel filter, the maximum temperature of 120 °C .

Meltblown filter with polypropylene as raw material, the filter is formed by melt blowing process, the highest working temperature 60 °C . Suspended matter, precision filter can remove some colloidal substances and fine particles.

Stainless steel filter housing precision filter Product features:

1, material and structure

Cylindrical shell, which is made up of 304 or 316L stainless steel;

With one or a plurality of filter;

Customers can request the material order processing.

Stainless steel filter housing precision filter model:

Shell material: 304, 316L stainless steel, carbon steel and resin shell optional;

Cartridge number: 1 core, 2 core, 3 core...... ;

The filter length: single section, two section, three section, four section (each 10 "is a section);

The filter installation forms: International flat pressing, clamping and inserting type;

The cylinder is connected with the base mode: fast open type (Q), flange type (F);

Connection: export medium, fast open type (Q), thread (S) and flange type (F);

Filter media: liquid (L), gas (G).
