Porous stainless steel sintered plate
- materials:SS316L
- filtering rate:0.2-50um
- thickness:0.6-10MM
- weight:0.5kg
- Product description: Sintered porous stainless steel filters : SUS 316L filter disc, sintering SS filter cartridge,powder sintered stainless steel filter tube, stainless sintering filter SS porous plate, microns powder st
Product introduction
Porous stainless steel sintered plate
1.Material: S304,S304L, S316, S316L
2.thickness:0.6-10mm( tolerance +/_0.05MM)
3.Max width 340MM , Max lenght 1000mm
4.Application
separating and purification solid and liquid, gas and solid, gas and liquid in the area of petroleum, chemical industry, metallurgy, aviation, electron, electric power, cima labs, pro-environment, atomic energy, nuke industry, natural gas, material of fire-resistant, fire-fighting equipment and so on.
Such as: sea water desalinization and sewage treatment, prefiltration and fine filter oil like transformer oil, lubricating oil and fuel oil, prefiltration and fine filter kinds of liquid like organic solution, inorganic solution, liquid medicine and beverage, dust removal for sundry gas and steam, degerming, unoil and demist, sound attenuation, arrest flame, deter heat, catalytic reaction, filtration of catalyst, buffer gas, sweats, divergence and cooling, produce perforated electrode and anti-icer etc.
5.Packaging Detail: Wooden cases or according to your requirements
sintered stailess steel filter elements technical parameters:
Filtering Level |
Filtration Precision um |
Maximum Hole Diameter um |
Permeability Coefficient 10-12m2 |
Permeability m3/h.m2.kpa |
Thickness mm |
Compression Strength Mpa/cm2 |
Bubbling Pressure Kpa |
S9 |
0.2 |
2.5 |
|
1 |
0.6-10 |
3.0 |
|
S8 |
0.5 |
4 |
|
3 |
0.6-10 |
3.0 |
|
S7 |
1.5 |
6 |
|
5 |
0.6-10 |
3.0 |
|
S6 |
2.5 |
10 |
0.09 |
10 |
0.6-10 |
3.0 |
9.16 |
S5 |
5 |
15 |
0.23 |
40 |
0.6-10 |
3.0 |
6.1 |
8 |
20 |
0.91 |
80 |
0.6-10 |
3.0 |
4.6 |
|
S4 |
10 |
30 |
1.81 |
160 |
0.6-10 |
3.0 |
2.6 |
S3 |
28 |
60 |
3.82 |
350 |
0.6-10 |
3.0 |
1.8 |
35 |
80 |
7.29 |
500 |
0.6-10 |
3.0 |
1.4 |
|
S2 |
40 |
100 |
9.43 |
700 |
0.6-10 |
3.0 |
1.1 |
S1 |
65 |
160 |
15.1 |
1000 |
0.6-10 |
3.0 |
0.66 |
