porous filter plates Sintered Metal Plate
- TH0.6-3mm
- Filtering precision:28%-50%
- FILTERING PRECISION: 0.45μm - 120μm
- COMPRESSIVE STRENGTH: 0.5-1.5MPa
- Product description: microns porous metal engineered assemblies, microns sintering porous metal filter material, sintered porous titanium cartridge filter tube, sintering titanium filter plate, microns sinter titanium dis
Product introduction
Sintered Porous Metal Filter are made of bronze,stainless steel and titanium ball or irregular powders.This filter elements via with high temperature sintering process to be any shape by the moulds.
Sintered Metal Filter are widely used in chemical , petroleum,metallurgy, air craft, gas, electronic,pharmacy and etc fields.
Application Capacities:
Filtering of Solid & Liquid
Filtering of Liquid & Gas
Filtering of Gas & Solid
Filter Rating:
Sintered Filter Elements have different aperture,porosity and filter rating.The general filter rating are 0.1um-80um.
Technical Data:
Media |
Micron
(µ) |
Aperture
(µ) |
Pressure
(MPa) |
Temperature
(°C) |
Application |
Stainless Steel |
0.2-0.8 |
2.5-160 |
3 |
≤ 600 |
Acid,Hydrogen,Vapour, Sulphide,Gas,Dedusting |
Tatinium |
0.2-0.8 |
2.5-160 |
2-3 |
≤ 300 |
Acid,Sea Water,Gas |
Bronze |
5-80 |
4-160 |
2-2.5 |
≤ 300 |
Air,Water,Oil,Organic Solvent |
Ni &Alloy |
0.5-60 |
3-100 |
2-2.5 |
≤ 550 |
Alkali,Acid,Liquid |
Alloy |
1-80 |
6-150 |
1.5-3 |
≤ 1000 |
Organic Solvent,Acid |
Features and Benefits:
*Working Temperature:-200-1000°C
*Corrosion Resistance
*High Filtering Efficiency
*Metallic capacities,such as noise reduction,hot resistance,heat conduction, high strength and etc.
*Easy to welding and long working life
Filter Shape:
Could be cartridge,disc,plate,sheet,cap and etc.
