China Titanium Powder Sintered Filter cartridge
- high purity titanium
- diameter:OD30 OD40 OD50 D60 D80 OD100
- Porosity:28~50%
- Temperature tolerance≤300°C (wet)
- Product description: China Titanium Powder Sintered Filter cartridge ,Sintered titanium water filter,Powder Sintered Stainless Steel Filter Plate,high quality titanium sintered plates for filter porous titanium plate,pure
Product introduction
China Titanium Powder Sintered Filter cartridge
1. Product Description
The filtration media of Titanium Sintered filter cartridge is high purity titanium as the material. It is made by sintering in high temperature and vacuum, with unique properties.
2. Specifications
Filter medium | high purity titanium |
Relative filtration pore size | 0.22~80 µm |
Length | 5",8" 10", 20", 30" |
Sealing material | Silastic, NBR, EPDM, Viton |
Porosity | 28~50% |
Diameter | OD30 OD40 OD50 D60 D80 OD100 |
Temperature tolerance | ≤300°C (wet) |
Max. working pressure | 0.6 MPa |
Pure water flow rate reference table: the initial value of 10’’cartridge L/H
(P=0.2 MPa, 1cP, 25°C)
Micro rating(um) | 0.2 | 0.45 | 1 | 2 | 3 | 5 | 10 | 20 | 30 | 50 | 80 |
Flow rate(L/H) | 180 | 200 | 250 | 280 | 300 | 350 | 500 | 800 | 1000 | 1500 | 1600 |
3. Features
High temperature resistant and used many times
washable for re-use and maximum economy
A large number of pores, uniform pore, small resistance, great permeability.
With excellent high and low temperature resistance, long service life, easy regeneration.
4. Applications
-Widely used in various media of the separation and filtration of gas or liquid.
- Suitable for filtering in the media of strong acid, strong alkali and high temperature.
